Description
- High-resolution 7-inch TFT color display
- Parameters: ECG, NIBP, temperature, SpO2
- Waveform: Biphasic
- Defibrillator type: Manual external synchronous and asynchronous defibrillation
- Charge time: Less than 10 seconds to 360 J
- Energy display: Monitor shows both selected and delivered energy
- Charge prompts: Voice and visual prompts
- Energy selection: 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 J
- Standard adult and pediatric paddles: Reusable external adult paddles with integrated pediatric paddles
- Battery: Li1104c 11.1 VDC 4000 mAh x2, up to 10 hours ECG monitoring or 60 full-energy discharges
- Low battery indicator: Flashing low-battery icon on display and battery indicator on device panel
- Recharge rate: 80% in 3 hours, 100% in 5 hours
- Built-in recorder: 50 mm thermal paper, high-resolution thermal print head
- Recorder outputs: Date, time, sweep speed, waveform gain, heart rate, energy (joule), and ECG waveform
- Print modes: HR exceed-limits alarm recording, auto-timed recording, real-time recording, defibrillation discharge trigger recording
- Power: AC-DC dual-use, battery operation, AC 100–240 V, 50/60 Hz
- Vehicle voltage option: DC 12 V
- Maximum power: 600 W
- Cumulant management: 4 different auto cumulant modes
- Patented DPS system: Dynamic pressure monitoring and automatic pressure release system
- 10 working modes: Rate, time, weight, drip, dose time, intermittent, ramp, micro, first dose, sequential
