Description
- LCD screen: 10.1"
- Minimum tidal volume: Down to 15 ml
- Audio and visual alarms: No tidal volume, MV, Paw, FiO2, air failure, AC power failure, battery low
- Standard ventilation modes: Manual, VCV, Standby, A/C, SIMV
- Anesthesia gas delivery: O2, N2O
- Built-in vaporizers: Isoflurane and Sevoflurane
- Tidal volume range: 20–1500 ml
- Pressure range: 5–60 cmH2O
- Respiration rate: 1–100 bpm
- Minute volume range: ≥ 18 L/min
- Working type: Electronically controlled, pneumatically driven
- Pipeline input range: 280–600 kPa
- FiO2, ACGO, battery runtime over 180 minutes
- Power supply: AC 110–240 V, 50/60 Hz
- Waveforms: P-T, F-T, V-T
- Highly integrated respiratory circuits
