Features
• Available in 3m & 6m lengths from 12mm to 108mm
• Adopts continuous casting and rolling production process, high purity, fine structure and low oxygen content
• No porosity, trachoma, loose, good thermal conductivity, processability, ductility, corrosion resistance and weather resistance. Easy to solder and braze
• Straight tube plastic film winding, can be plugged, can be loaded with wooden boxes
• The product quality is stable, the pressure is high, the elongation rate is high, and the cleanliness is high, which meets the high cleaning requirements of the fluorine-free refrigeration equipment
Technical Data
| Model | Diameter (mm) | Thickness (mm) | Working Pressure(Bar) |
|---|---|---|---|
| CP-12 | 12 | 12 | 77 |
| CP-15 | 15 | 15 | 63 |
| CP-22 | 22 | 22 | 58 |
| CP-28 | 28 | 28 | 51 |
| CP-35 | 35 | 35 | 40 |
| CP-42 | 42 | 42 | 35 |
| CP-54 | 54 | 54 | 27 |
| CP-67 | 67 | 67 | 26 |
| CP-76 | 76 | 76 | 29 |
| CP-108 | 108 | 108 | 16 |
