X-Ray tube high voltage: 60KV
X-Ray tube current: 2mA
Loading leaked radiation: <0.25mg/h
Skin focal length: 200mm
Lithium Battery capacity: 14.8V/2500mAh
Working frequency: 30HZ
Focus on management: 0.7mm*0.7mm
Exposure time: 0.1 – 2.0s
Non-loaded leakage radiation: <0mg/h
Limit the diameter of the line field: 58mm
Tube lifespan: On average 10,000 hrs
Whole Machine weight: 1.92kg
