• Flow control: 5LPM~15LPM
• Oxygen concentration: 21%~100%
• Air supply failure: While air source interrupted or the pressure difference more than 0.1MPa,it shall alarmed by sound
• Sound alarm: At least continue 60s,and the level of sound shall more than 60dB(A)
• Pressure gauge: -2~10KPa(-20~100cmH2O)
• MAX-P: @ 0~15LPM ≤6kPa(60cmH2O)
• PIP: @5~15LPM 0.2~5.7kPa(2~57cmH2O)
• PEEP: @5~15LPM 0.03~2.3kPa(0.3~23cmH2O)
• Working noise: ≤55dB(A)
• Work and store limit: -20ºC~50ºC, relative humidity up to 90%
• Work hours(400L gas cylinder): @8LPM /50mins
NICU, Resuscitator
Infant Resuscitator Mounting Bracket
An infant resuscitator mounting bracket is an accessory designed for medical devices that secures neonatal resuscitation units, such as the Fisher & Paykel Neopuff or NeoPIP. These brackets can be attached to vertical or horizontal surfaces, including vacuum brackets, IV poles, or medical rails. They are highly versatile and can accommodate rail systems measuring between 2.5 cm to 5.5 cm wide and 1 cm thick.
