• Detector Technology: a-Si
• Scintillator: CSI
• Active Area: 430×430 mm
• Pixel Matrix: 3072×3072
• Pixel Pitch: 139μm
• AD Conversion: 16bit
• Maximum Linear Dose(μGy): 110
• Ghost: <0.25%
• DQE @1.0 LP/MM(2.5μGy): 42%
• Full View Time: 1.5s
• MTF @1.0 LP/mm: 63%
• Data Interface: GBE
• Limiting Resolution: 3.6LP/mm
• Exposure Control: Software/Outer/AED
• Adapter Input: AC 100-240V, 50-60Hz
• Adapter Output: DC 24V, 2.5A
• External Dimensions: 460×460×14.8 mm
• Housing Material: Carbon, Alloy
• Ingress Protection: IPX3
• Work Environment: 10-35°C, 30-85%RH
• Power Dissipation: 20 W
• Energy Range: 40-150 kVp
• Weight: 3.9kg
