Display: Colour LCD, 12.1-inch touch screen
Multi-mode ventilation function: VCV, SIMV, SIMV/PSV, PSV, PCV, ARPV, APNEA, V-A/C, CPAP, BIPAP, Manual, SIGH
Dimensions & Weight: 45*55*140cm, 65kg
Castors: Front wheels with lock
Display graphics: P-T, F-T, V-T
Loops: P-V, F-V, F-P
Gas configuration: O2, Air
Pipeline input range: 280-600kPa
Output pressure: 0.4 – 0.1MPa
Noise: </=50dB
Battery: Lead-acid 12V, 4Ah with 180+ run time
Ventilator parameter: Tidal volume range: 10-2000ml, Pressure range: 5-80cmH2O, Respiration rate range: 1-1000bpm (1-40bpm under SIMV), Inpiration time: 0.2-12s, Pressure control: 0-80cmH2O, Inspirational plateau: OFF, 1-50%, SIGH: OFF, 1-5/100%, Ptrigger range: -20-0cmH2O, Ftrigger range: 0.5-30L
PEEP: Integrated, Electronic control, Range: OFF, 3-40cmH2O
Parameter monitoring: Pti, Vte, Pmean, Pplateau, PEEP, NIF, FlowEMax, Frep T, FrepSp, FrepM, MVsp, MVleak, Vtrdeep. RVR (RSBI), Ri, Rex, Cs, Cdyn, WOB, RCexp, FiO2.
Alarms (Audio/Visual): No tidal volume, MV, Paw, FiO2 limitationO2, Air failure, AC power failure, backup low
Preseting function: Language: English, Automatic self-test
Oxygen remedy: Up to 60L/min
Operating temp.: 50C -400C
Storage temp.: -100C-+400C, Humidity: </80%
Atmosphere pressure: 960 hPa – 1040 hPa
Oxygen remedy: Up to 60L/min
Applied with invasive ventilation and non-invasive ventilation
