Overall size: 1500?1360?1950mm
Chamber size: 1200?610?910mm
Steam consumption: 30KG
Tap waterconsumption: 45kg
Power: 3+36KW
Body of the sterilizer: Tank of the horizontal rectangular double-deck structure is made from S30408,
Door sealing: Pneumatic sealing; both doors are interlocked and completely conform to the requirements of the specification.
The equipment has standard GMP authentication interface.
Sterilizer piping system: Designed with tmported parts and quality domestic brands into main components.
Sterilizer control system: Adopts of Siemens PLC plus
Siemens touch screen, program selection, parameter setting, equipment operation and report processing.
It has perfect safety measures. The F0 value and the temperature time gives double guarantee for sterilization.
A single parameter control is also available. It has a perfect sterilization records
