| Model | Door Type | Application | Chamber Vol. (Liters) | Dimensions W x H x D (mm) | Washing Levels | DIN Baskets | Programs |
|---|---|---|---|---|---|---|---|
| TIVA8-1M | Manual double glass door | Clinics & Dental Practices |
165 | 600x650x860 | 4 | 8 | 40 |
| TIVA8-WD-1M / TIVA8-HS-1M | Manual double glass door | 165 | 900x650x860 | 4 | 8 | 40 | |
| TIVA10-1M / TIVA10-2M | Manual double hinged glass door | Surgical & Sterilization Departments |
265 | 650x700x1850 | 6 | 12 | 40 |
| TIVA10-1M-HS / TIVA10-2M-HS | Manual double hinged glass door | 265 | 650x700x2200 | 6 | 12 | 40 | |
| TIVA10-1V / TIVA10-2V | Automatic sliding glass doors | Surgical & Sterilization Departments |
265 | 680x700x1950 | 6 | 12 | 40 |
| TIVA10-1V-HS / TIVA10-2V-HS | Automatic sliding glass doors | 265 | 680x700x2300 | 6 | 12 | 40 | |
| TIVA15-1V / TIVA15-2V | Automatic sliding doors | Surgical & Sterilization Departments |
430 | 1000x900x1900 | 6 | 18 | 40 |
| TIVA15-1V-HS / TIVA15-2V-HS | Automatic sliding doors | 430 | 1000x900x2300 | 6 | 18 | 40 |
| Application | Medical instrument washing, disinfection & drying | Process | Pre-wash, washing, rinsing, thermal disinfection & drying |
| Chamber Material | AISI 316L stainless steel | Frame Material | AISI 304 stainless steel |
| Control System | Touchscreen control system | Display | Color graphic display |
| Programs | Up to 40 preset & programmable programs | Drying System | Hot-air drying with prefilter & HEPA H14 filter |
| Heating | 3 heating elements | Steam Condenser | Built-in steam condenser |
| Detergent Dosing | 2 dosing pumps with flowmeters | Additional Pumps | Optional additional dosing pumps |
| Water Quality | Optional conductivity measurement | Load Recognition | Automatic washing trolley recognition |
| Spray Arm Monitoring | Continuous monitoring of spray-arm operation | Chamber Lighting | Multi-color LED chamber light |
| Data Documentation | USB / printer; RS232 on applicable models | Cycle Reports | Graphic reports including time & temperature |
| Door | Tempered/double glass design depending on model | Visibility | Visual monitoring of washing process |
| Drying Air | HEPA H14 filtered air | Energy Efficiency | Steam condenser reduces energy use & drying time |
| Water Connections | Cold/softened & purified/demineralized water options | Steam Connection | Utility steam/hybrid heating available on applicable models |
| Pass-Through | Pass-through configuration available on applicable models | Floor Space | Space-efficient design |
| Safety & Monitoring | Process parameter monitoring & cycle validation | Accessories | Wide range of washing trolleys & accessories |
