For sterilizing heat sensitive medical equipment
Highly effective sterile processing for operating rooms and Sterile Processing Departments (SPD). Using eco-friendly VHP (Vaporized Hydrogen Peroxide) sterilizing agent the PlazMax sterilizer inactivates micro-organisms. The hydrogen peroxide safely and quickly sterilizes instruments and materials without leaving dangerous residues, offering effective, reliable, and economical sterilization.
Technical Specifications
| Model | Chamber Volume (Liter) |
External Dimensions (WxHxD/D 2-doors) mm |
No. of Baskets (WxD cm) |
Power (W) Current (A) |
Voltage (V) 1-Phase 50-60 Hz |
|---|---|---|---|---|---|
| P50 | 47 | 702 x 1528 x 729 / 736 | 1 (40 x 60) | 3100 W 13.5 A | 230 V |
| P110 | 110 | 702 x 1768 x 729 / 736 | 2 (40 x 60) | 4300 W 18.7 A | 230 V |
| P160 | 162 | 702 x 1768 x 1029 / 1036 | 2 (40 x 90) | 4300 W 18.7 A | 230 V |
Sterilization Cycle and Test Programs
| Model | Normal Cycle (Non-hollow loads) |
Advanced Cycle (Hollow loads) |
Heavy Duty Cycle (Hollow and Non-hollow loads, Containers) |
Endoscope * |
|---|---|---|---|---|
| Cycle Time (min.) | Cycle Time (min.) | Cycle Time (min.) | Cycle Time (min.) | |
| P50 | 35 | 40 | 50 | 28 |
| P110 | 39 | 44 | 55 | 30 |
| P160 | 43 | 48 | 60 | 41 |
| Test Cycles | Description |
|---|---|
| Test I | Penetration Test |
| Test II | Leakage Test |
